Variable Height Arm With Wall Workstation
Product detailed information
Variable Height Arm With Wall Workstation Specification
- Height adjust method : The height can be locked and released by a single-click
- Height adjustment : 450mm
- Total arm maximum load: 1000Ngas spring load：2~5 Kg
- 1500Ngas spring load：5~8kg
- 2000Ngas spring load：8~12kg
Create Datasheet
Select options on the right and create a customized datasheet.
Basic Information
| Model | WM800-08525/WM800-08524 | Channel | Optional Channel 482mm /320mm |
|---|---|---|---|
| Arm length | 524mm | Height adjust method | The height can be locked and released by a single-click |
| Height adjustment | 450mm | Swivel range | + - 90° |
| Tilt range | 0~ 200° | Total arm maximum load | 1000Ngas spring load：2~5Kg/1500Ngas spring load：5~8kg/2000Ngas spring load：8~12kg |
| Screen Size | 24inch | Screen Max weight | 10kg |
| Keyboard Max weigh | 2kg | Keyboard Max Size | 158*442mm |
| Concealed cabling | Yes | Color | Medical White |
| Material | Aluminum Alloy | Main Processing Method | Designed with a die-cast aluminum core for strength |
| Net Weight | 7.5kg | Application | Anesthesia machine、Patient monitor , screen |
Product Description
This CORITON product is designed as a mobile computer workstation, medical mounting arm for Computer, Workstation applications. It is suitable for hospital wards, outpatient rooms, emergency departments, diagnostic areas, and mobile clinical workflows where stable device support, organized accessories, and reliable movement between care areas are required. This product can support OEM/ODM medical trolley and mounting projects that need practical installation, durable structure, and clean equipment integration.
